When someone joins, moves or leaves in INAZ, you want that change reflected in your on-premise Active Directory without anyone touching it by hand. To connect INAZ to Active Directory, Joinly reads each HR change in HR Inaz over the export your deployment provides and applies it to your domain through the Joinly AD Agent — a lightweight connector that runs inside your network. INAZ stays your source of truth; Joinly is the engine that keeps every account in the right OU, accurate and traceable.

Key takeaways

  • HR Inaz stays your source of truth; Joinly applies every joiner, mover and leaver to on-premise Active Directory automatically.

  • The Joinly AD Agent runs inside your network and needs only an outbound HTTPS connection — no inbound ports and no domain controller exposed to the internet.

  • Joinly maps INAZ structures — the organization chart and cost centres — to the right AD security groups and target OUs, and builds the sAMAccountName, UPN and distinguished name from your own rules.

  • Because there is no native INAZ-to-AD connector, the AD Agent replaces the manual list-and-re-key routine with rule-based provisioning, placing each account in the correct OU on the start date.

  • Every action is logged for a complete audit trail, aligned with NIS2 and ISO 27001 — and the same setup extends to a hybrid Entra ID environment.

INAZ

Joiner

Mover

Leaver

On-premise Active Directory (AD DS)

Quick facts

Source system

INAZ (HR Inaz)

Target system

On-premise Active Directory (AD DS)

Connection method

INAZ HR export (file / record path, database or middleware) → Joinly AD Agent → Active Directory

Agent requirement

Domain-joined Windows server with a GMSA, outbound HTTPS (443) only

Supported events

Joiner, mover, leaver (incl. rehire and internal transfer)

Synced attributes

Name, sAMAccountName, UPN, mail, department, job title, manager, cost centre, distinguished name / OU, start and end date

Real-time or batch

Frequent sync, multiple times per day

Compliance

ISO 27001, NIS2-ready, GDPR (EU data centre)

How does Joinly sync INAZ to Active Directory?

Joinly reads each HR change in HR Inaz in the cloud, then hands the action to the Joinly AD Agent inside your network, which makes the change in Active Directory. INAZ holds the authoritative employee dossier; the agent is the only component that touches your domain.

  1. Joiner. HR completes the hire in HR Inaz. Joinly reads the new resource’s dossier, determines the role from department, job title and cost centre, and instructs the AD Agent to create the user in the correct OU, build the sAMAccountName and UPN from your rules, and add the right security groups — timed to the start date recorded in INAZ.

  2. Mover. When someone changes position, department or cost centre, Joinly tells the agent to move the user to the matching OU, swap security-group membership and update attributes. Access that no longer fits the new position is removed, so permissions stay aligned with the actual job.

  3. Leaver. On the end date recorded in INAZ, Joinly instructs the agent to disable the AD account and optionally move it to a disabled-users OU. A grace window keeps the object recoverable in case of a quick rehire.

Example: A logistics and transport company runs HR Inaz and an on-premise AD across three depots. It hires a warehouse operative with a start date next Monday. Joinly reads the INAZ dossier, and on Monday morning the AD Agent creates the user in the Depot-North > Operations OU, sets the sAMAccountName to a unique pattern, and adds the Warehouse-Operations group. When the operative later moves to dispatch, the agent moves the object to the new OU and swaps the groups the same day.

What manual AD account management costs

Without automation, every account starts as an INAZ export that an admin works through in Active Directory Users and Computers by hand — creating the object, choosing the OU, building the sAMAccountName, adding groups. Because there is no native INAZ-to-AD path, even a home-built feed offers limited mapping and no role-to-group logic, so the decisions still fall to people.

  • Onboarding delays. New joiners wait for an AD account and group access while a request sits in a queue, losing productive days in their first week.

  • Permissions that don’t keep up (privilege creep). When movers change position, old security-group membership often stays attached, so people accumulate rights they no longer need.

  • Forgotten offboarding. Accounts that aren’t disabled on time are a security and audit risk — especially when the only trigger is a manual note from HR that the person has left.

Joinly vs. the Entra provisioning agent for AD

There is no native INAZ-to-AD connector, so the realistic baseline is Microsoft’s Entra provisioning agent driven by a file feed. It can write attributes to on-premise AD, but it stops short of the part that actually decides access. Here’s how the two compare for an INAZ-driven AD setup.


Joinly AD Agent

Entra provisioning agent (file feed → AD)

Source

Reads the INAZ HR export directly, whatever the deployment

Needs a hand-built file feed; no INAZ template

OU placement

Rule-based on org chart and cost centre

Single configured container; limited logic

Role-to-group mapping

Built in, rule-based

Not available out of the box; manual

Future-dated hires

Times creation to the INAZ start date

Needs custom date-window configuration

Deployment coverage

Adapts to on-premise, SaaS/ASP/Cloud or BPO INAZ

Assumes one stable feed format

sAMAccountName / UPN rules

Custom transformation with uniqueness fallback

Limited expression mapping

Audit trail

Per-action logging tied to the HR source

Limited

Watch-outs when connecting INAZ to Active Directory

A few details decide whether this connection stays reliable at scale.

  • sAMAccountName uniqueness and length. AD limits the sAMAccountName to 20 characters and it must be unique across the domain. Joinly builds it from your rules with a fallback pattern, so duplicate names never produce a collision or a truncated, unreadable login.

  • OU placement from the organization chart. The INAZ organization chart, function charts and cost centres don’t map one-to-one to your OU structure. Joinly builds explicit rules that place each user — and move them on a transfer — into the correct OU.

  • No standard provisioning API. INAZ does not publish a general-purpose provisioning API and its data path depends on how it is deployed. Joinly reads the structured export, database or middleware channel your instance exposes and drives the agent from it, so the lack of an API doesn’t block automation.

  • Italian payroll fields. INAZ carries Italian-specific data such as CCNL contractual tables and the codice fiscale that you rarely want in AD. Joinly maps only the attributes you need, so the right fields reach AD and the rest stay in INAZ.

  • Service-account permissions. The agent acts under a service account with delegated rights. Joinly works with least-privilege delegation scoped to the target OUs, so the agent can create, move and disable users without domain-admin rights.

Joinly handles each of these by default with custom mapping and transformation.

Always audit-ready

Every account action the Joinly AD Agent performs is logged in the Joinly cloud: who was affected, when it happened, which OU and groups changed and which INAZ change triggered it. For NIS2 that matters directly: access can be traced back to an authorised HR source rather than an ad-hoc request. Joinly is ISO 27001 certified, runs in an EU data centre in Amsterdam, applies least-privilege by default, and is built to meet NIS2 and ISO 27001.

Example case

Take a logistics and transport operator with around 1,800 employees across warehouses, depots and a head office in Italy, running HR Inaz but still living in an on-premise Active Directory for its warehouse and fleet systems. Every new driver, warehouse operative or dispatcher starts as an INAZ export line that IT processes by hand in AD — creating the object, choosing the OU, building the login, adding groups. With shift work, seasonal peaks and frequent moves between depots the queue never empties, and new joiners wait until day two or three for their account.

Connect INAZ to Active Directory with Joinly and that work disappears. The Joinly AD Agent creates each user in the right OU on the start date, builds a unique sAMAccountName, adds the correct security groups, moves people on a transfer and disables accounts on the end date with a 30-day grace window — all driven by the HR change in HR Inaz.

“An account is simply ready in the right depot OU when the driver starts, moves between sites take care of themselves, and we can show the auditor exactly which INAZ change created every bit of access.” — Head of IT, logistics and transport operator

The outcome this setup is designed for: onboarding drops from days to zero touch, privilege creep from old roles is eliminated, and the team can walk into its next NIS2 assessment with a complete, source-backed audit trail.

More than a connector

A standalone INAZ to Active Directory connection is a good start, but identity rarely stops at one target. The same Joinly setup extends to Entra ID for a hybrid environment and to your other systems, managing the complete chain from joiner to leaver with logging and governance built in. You review the exceptions; Joinly maintains the chain.

Schedule a demo

Installation manual

Installation manual

Connect INAZ to Active Directory (on-premise)

Connect INAZ to Active Directory (on-premise)

Installation guide

Follow these steps to connect INAZ to your on-premise Active Directory with Joinly. Most of the setup happens in the cloud platform; the only local component is the lightweight Joinly AD Agent, which you install on a domain-joined server.

1. Create your account

Go to platform.joinly.app and create your account.

Note: charges may apply for using the platform after the trial period ends.


Joinly account creation screen at platform.joinly.app


Sign up at platform.joinly.app to get started.

2. Find the INAZ integration in the Joinly marketplace

Open the Joinly marketplace and search for the INAZ integration.

Don’t see your system listed? Get in touch at support@koppelhet.nl and we’ll help you out.


Joinly marketplace showing available HR integrations


Search the marketplace for the INAZ integration.

3. Follow the installation wizard

You may be redirected to integrations.joinly.app. Create an account there and enter your INAZ connection details. Because INAZ can be deployed on-premise, as SaaS/ASP/Cloud or through a BPO service, the wizard asks for the channel your instance exposes — a scheduled structured export (file / record path), a database endpoint or a middleware feed. All data is encrypted and stored securely.


Joinly installation wizard for entering INAZ connection details


Enter your INAZ connection details in the wizard.

4. Download the Joinly AD Agent

In the platform, go to Workflows → Select a workflow → Add action → Select ‘Provisioning via Agent’ and download the installer. The agent is a lightweight Windows service that connects your domain to the Joinly cloud over an outbound HTTPS connection only — there are no inbound ports to open.


Joinly platform screen to download the AD Agent installer


Download the Joinly AD Agent installer from the provisioning settings.

5. Install the agent on a domain-joined server

Run the installer on a domain-joined Windows server that can reach a domain controller. The server needs outbound HTTPS (port 443) to the Joinly cloud and a GMSA account installation on your domain controller. Run through the installer; it registers the agent as a Windows service that starts automatically.

6. Pair the agent with your Joinly tenant

Copy the pairing token from Settings → Provisioning → AD Agent in the platform and paste it into the agent’s configuration screen. The agent uses the token to register securely with your tenant; once paired, its status shows as Connected in the platform.


Joinly AD Agent pairing screen with a connection token


Pair the agent with your tenant using the pairing token.

7. Set the target OU and attribute mapping

Configure where users are created and how their attributes are built. Map the distinguished name / OU from the INAZ organization chart and cost centres, and build the sAMAccountName, userPrincipalName, mail, department and manager with Liquid templates.


Joinly field mapping screen for INAZ to Active Directory attributes


Select the OU and attribute mapping.

8. Configure your workflows

Create an onboarding (joiner) and offboarding (leaver) workflow with trigger-based execution, then an Identity updated workflow with a Create/update employee in Active Directory action so every change in HR Inaz flows through the agent to AD. Add a threshold workflow that disables the account a set period after the end date (for example 30 days), optionally moving it to a disabled-users OU.


Joinly workflow editor creating an employee onboarding workflow


Create a trigger-based onboarding workflow.


Creating a threshold workflow that runs days after the end date


A date-threshold workflow disables accounts a set number of days after the end date.

9. Network and firewall requirements

The agent needs outbound HTTPS (443) to the Joinly cloud and a GMSA account with PowerShell access to your domain controllers. No inbound firewall rules are required, and no domain controller is exposed to the internet. For high availability you can run the agent on more than one server.

Need cloud Entra ID provisioning as well? See our guide on connecting INAZ to Microsoft Entra ID, or contact support at support@koppelhet.nl.

Frequently asked questions

Does the Joinly AD Agent need inbound firewall openings?
No. The agent only makes an outbound HTTPS connection to the Joinly cloud and acts on your domain controllers from inside the network through a GMSA with PowerShell access. There are no inbound ports to open and no domain controller is exposed to the internet.

What account does the agent run under?
A Group Managed Service Account (GMSA) with PowerShell access to your domain controllers, scoped to the target OUs so it can create, move and disable user objects without domain-admin rights.

Which OU do new accounts land in?
The one your rules define. Joinly builds the distinguished name and OU placement from the INAZ organization chart and cost centres, and moves the object to a new OU automatically when someone transfers.

How is the sAMAccountName built and kept unique?
From your Liquid template, with the generateUniqueUsername helper falling back to the next pattern on a collision, all within AD’s 20-character limit.

Can I provision to both Active Directory and Entra ID?
Yes. The same Joinly setup drives a hybrid environment — the AD Agent for on-premise AD and the native Entra connection for the cloud. See the INAZ to Entra ID guide.

Can I run more than one agent for high availability?
Yes. You can install the agent on multiple domain-joined servers so provisioning continues if one server is unavailable.
