When someone joins, moves or leaves in Nmbrs, you want that change reflected in your on-premise Active Directory without anyone touching it by hand. To connect Nmbrs to Active Directory, Joinly reads each HR change through the Nmbrs REST API and applies it to your domain through the Joinly AD Agent — a lightweight connector that runs inside your network. Nmbrs stays your source of truth; Joinly is the engine that keeps every account in the right OU, accurate and traceable.

Key takeaways

  • Nmbrs stays your source of truth; Joinly applies every joiner, mover and leaver to on-premise Active Directory automatically.

  • The Joinly AD Agent runs inside your network and needs only an outbound HTTPS connection — no inbound ports and no domain controller exposed to the internet.

  • Joinly maps Nmbrs departments and functions to the right AD security groups and target OUs, and builds the sAMAccountName, UPN and distinguished name from your own rules.

  • Because Nmbrs is payroll-first and often has no work email, the Joinly AD Agent builds a unique sAMAccountName and UPN from the name fields, and times creation to the service-interval start date.

  • Every action is logged for a complete audit trail, aligned with NIS2 and ISO 27001 — and the same setup extends to a hybrid Entra ID environment.

Nmbrs

Joiner

Mover

Leaver

On-premise Active Directory (AD DS)

Quick facts

Source system

Nmbrs (Visma)

Target system

On-premise Active Directory (AD DS)

Connection method

Nmbrs REST API → Joinly AD Agent → Active Directory

Agent requirement

Domain-joined Windows server with a GMSA, outbound HTTPS (443) only

Supported events

Joiner, mover, leaver (incl. rehire and multiple service intervals)

Synced attributes

Name, sAMAccountName, UPN, mail, department, function (job title), manager, company, employee number, distinguished name / OU, service-interval start and end date

Real-time or batch

Frequent sync, multiple times per day

Compliance

ISO 27001, NIS2-ready, GDPR (EU data centre)

How does Joinly sync Nmbrs to Active Directory?

Joinly reads each HR change in Nmbrs in the cloud through the REST API, then hands the action to the Joinly AD Agent inside your network, which makes the change in Active Directory. Nmbrs holds the authoritative employment record — the service interval, department and function; the agent is the only component that touches your domain.

  1. Joiner. The salary administrator completes the hire in Nmbrs. Joinly reads the new employee and their service interval, determines the role from the company, department and function, and instructs the AD Agent to create the user in the correct OU, build the sAMAccountName and UPN from your rules, and add the right security groups — timed to the service-interval start date.

  2. Mover. When someone changes department, function or company in Nmbrs, Joinly tells the agent to move the user to the matching OU, swap security-group membership and update attributes. Because Nmbrs data is period-based, the change is applied in the period it takes effect, and access that no longer fits the new role is removed.

  3. Leaver. When the service interval is closed with an end date in Nmbrs, Joinly instructs the agent to disable the AD account and optionally move it to a disabled-users OU. Where a person holds more than one service interval, the account is only disabled when the last active interval ends.

Example: A wholesale and trade business runs Nmbrs and an on-premise AD across two branches and a warehouse. It hires a sales-desk employee with a service-interval start date next Monday. Joinly reads the record, and on Monday morning the AD Agent creates the user in the Branch-A > Sales OU, sets a unique sAMAccountName built from the name fields, and adds the Sales-Desk group. When that person later moves to purchasing, the agent moves the object to the new OU and swaps the groups the same day.

What manual AD account management costs

Without automation, every account starts as a message from the payroll administrator that an admin works through in Active Directory Users and Computers by hand — creating the object, choosing the OU, inventing a sAMAccountName because Nmbrs holds no work email, adding groups. A hand-built Nmbrs API integration offers limited mapping, no role-to-group logic and no service-interval timing, so the decisions still fall to people.

  • Onboarding delays. New joiners wait for an AD account and group access while a request sits in a queue, losing productive days in their first week.

  • Permissions that don’t keep up (privilege creep). When movers change department or function, old security-group membership often stays attached, so people accumulate rights they no longer need.

  • Forgotten offboarding. Accounts that aren’t disabled on time are a security and audit risk — and a service interval closed in payroll is easy to miss without a direct link to IT.

Joinly vs. a hand-built Nmbrs-to-AD integration

Because Nmbrs isn’t published as a native Entra ID provisioning app, writing its data into on-premise AD usually means a custom REST integration or a script. Both can push data, but they stop short of the part that actually decides access. Here’s how the two compare for a Nmbrs-driven AD setup.


Joinly AD Agent

Custom REST integration / script

Source

Reads the Nmbrs REST API directly

Reads Nmbrs directly

OU placement

Rule-based on department and function

Single configured container; limited logic

Role-to-group mapping

Built in, rule-based

Hand-coded; not out of the box

Service-interval timing

Times creation to the dienstverband start date

Needs custom date-window logic

Multiple service intervals

Resolves the active interval that drives the object

Easy to sync a closed or wrong interval

sAMAccountName / UPN rules

Custom transformation with uniqueness fallback

Manual pattern; collisions likely

Audit trail

Per-action logging tied to the HR source

Whatever you build yourself

Watch-outs when connecting Nmbrs to Active Directory

A few details decide whether this connection stays reliable at scale.

  • sAMAccountName uniqueness and length. AD limits the sAMAccountName to 20 characters and it must be unique across the domain — and because Nmbrs holds no work email, it has to be generated from the name fields. Joinly builds it from your rules with a fallback pattern, so duplicate names never produce a collision or a truncated, unreadable login.

  • OU placement from departments and functions. A debtor’s departments and functions don’t map one-to-one to your OU structure. Joinly builds explicit rules that place each user — and move them on a transfer — into the correct OU.

  • Service-interval (dienstverband) start date. In Nmbrs the service-interval start date is what payroll uses, and it isn’t always the calendar date the record was entered. Joinly reads the service-interval start date and has the agent create the account on the right day, not before.

  • Period-based moves and multiple service intervals. Department and function changes are stored per period, and an employee can hold more than one service interval, including a rehire. Joinly keeps a single, stable AD object driven by the active interval, so a move or rehire updates the right object rather than creating a duplicate.

  • Service-account permissions. The agent acts under a service account with delegated rights. Joinly works with least-privilege delegation scoped to the target OUs, so the agent can create, move and disable users without domain-admin rights.

Joinly handles each of these by default with custom mapping and transformation.

Always audit-ready

Every account action the Joinly AD Agent performs is logged in the Joinly cloud: who was affected, when it happened, which OU and groups changed and which Nmbrs change triggered it. For NIS2 that matters directly: access can be traced back to an authorised HR source rather than an ad-hoc request. Joinly is ISO 27001 certified, runs in an EU data centre in Amsterdam, applies least-privilege by default, and is built to meet NIS2 and ISO 27001.

Example case

Take a wholesale and trade SMB with around 320 employees across two branches and a central warehouse, running Nmbrs for HR and payroll but still living in an on-premise Active Directory for its ERP and warehouse systems. Every new sales-desk hire, warehouse worker or buyer starts as a message from the payroll administrator that IT processes by hand in AD — creating the object, choosing the OU, inventing a login because Nmbrs holds no email, adding groups. With seasonal peaks and frequent moves between branches the queue never empties, and new joiners wait until day two or three for their account.

Connect Nmbrs to Active Directory with Joinly and that work disappears. The Joinly AD Agent creates each user in the right OU on the service-interval start date, builds a unique sAMAccountName from the name fields, adds the correct security groups, moves people on a transfer and disables accounts when the service interval closes with a 30-day grace window — all driven by the HR change in Nmbrs.

“An account is simply ready in the right OU when the new hire walks in, moves between branches sort themselves out, and we can show the auditor exactly which change in Nmbrs created every bit of access.” — Head of IT, wholesale business

The outcome this setup is designed for: onboarding drops from days to zero touch, privilege creep from old roles is eliminated, and the team can walk into its next NIS2 assessment with a complete, source-backed audit trail.

More than a connector

A standalone Nmbrs to Active Directory connection is a good start, but identity rarely stops at one target. The same Joinly setup extends to Entra ID for a hybrid environment and to your other systems, managing the complete chain from joiner to leaver with logging and governance built in. You review the exceptions; Joinly maintains the chain.

Schedule a demo

Installation manual

Installation manual

Connect Nmbrs to Active Directory (on-premise)

Connect Nmbrs to Active Directory (on-premise)

Installation guide

Follow these steps to connect Nmbrs to your on-premise Active Directory with Joinly. Most of the setup happens in the cloud platform; the only local component is the lightweight Joinly AD Agent, which you install on a domain-joined server.

1. Create your account

Go to platform.joinly.app and create your account.

Note: charges may apply for using the platform after the trial period ends.


Joinly account creation screen at platform.joinly.app


Sign up at platform.joinly.app to get started.

2. Find the Nmbrs integration in the Joinly marketplace

Open the Joinly marketplace and search for the Nmbrs integration.

Don’t see your system listed? Get in touch at support@koppelhet.nl and we’ll help you out.


Joinly marketplace showing available HR integrations


Search the marketplace for the Nmbrs integration.

3. Follow the installation wizard

You may be redirected to integrations.joinly.app. Create an account there and authorise Joinly against Nmbrs. The Nmbrs REST API uses OAuth 2.0, so you sign in to Nmbrs and consent rather than storing a password. All data is encrypted and stored securely.


Joinly installation wizard for connecting to Nmbrs via OAuth


Authorise Joinly against Nmbrs with OAuth in the wizard.

4. Download the Joinly AD Agent

In the platform, go to Workflows → Select a workflow → Add action → Select ‘Provisioning via Agent’ and download the installer. The agent is a lightweight Windows service that connects your domain to the Joinly cloud over an outbound HTTPS connection only — there are no inbound ports to open.


Joinly platform screen to download the AD Agent installer


Download the Joinly AD Agent installer from the provisioning settings.

5. Install the agent on a domain-joined server

Run the installer on a domain-joined Windows server that can reach a domain controller. The server needs outbound HTTPS (port 443) to the Joinly cloud and a GMSA account installation on your domain controller. Run through the installer; it registers the agent as a Windows service that starts automatically.

6. Pair the agent with your Joinly tenant

Copy the pairing token from Settings → Provisioning → AD Agent in the platform and paste it into the agent’s configuration screen. The agent uses the token to register securely with your tenant; once paired, its status shows as Connected in the platform.


Joinly AD Agent pairing screen with a connection token


Pair the agent with your tenant using the pairing token.

7. Set the target OU and attribute mapping

Configure where users are created and how their attributes are built. Map the distinguished name / OU from the department and function, and build the sAMAccountName, userPrincipalName, mail, department and manager with Liquid templates.


Joinly field mapping screen for Nmbrs to Active Directory attributes


Select the OU and attribute mapping.

8. Configure your workflows

Create an onboarding (joiner) and offboarding (leaver) workflow with trigger-based execution, then an Identity updated workflow with a Create/update employee in Active Directory action so every change in Nmbrs flows through the agent to AD. Add a threshold workflow that disables the account a set period after the service-interval end date (for example 30 days), optionally moving it to a disabled-users OU.


Joinly workflow editor creating an employee onboarding workflow


Create a trigger-based onboarding workflow.


Creating a threshold workflow that runs days after the termination date


A date-threshold workflow disables accounts a set number of days after the service interval ends.

9. Network and firewall requirements

The agent needs outbound HTTPS (443) to the Joinly cloud and a GMSA account with PowerShell access to your domain controllers. No inbound firewall rules are required, and no domain controller is exposed to the internet. For high availability you can run the agent on more than one server.

Need cloud Entra ID provisioning as well? See our guide on connecting Nmbrs to Microsoft Entra ID, or contact support at support@koppelhet.nl.

Frequently asked questions

Does the Joinly AD Agent need inbound firewall openings?
No. The agent only makes an outbound HTTPS connection to the Joinly cloud and acts on your domain controllers from inside the network through a GMSA with PowerShell access. There are no inbound ports to open and no domain controller is exposed to the internet.

What account does the agent run under?
A Group Managed Service Account (GMSA) with PowerShell access to your domain controllers, scoped to the target OUs so it can create, move and disable user objects without domain-admin rights.

Which OU do new accounts land in?
The one your rules define. Joinly builds the distinguished name and OU placement from the Nmbrs department and function, and moves the object to a new OU automatically when someone transfers.

How is the sAMAccountName built and kept unique?
From your Liquid template — built from the name fields because Nmbrs holds no work email — with the generateUniqueUsername helper falling back to the next pattern on a collision, all within AD’s 20-character limit.

Can I provision to both Active Directory and Entra ID?
Yes. The same Joinly setup drives a hybrid environment — the AD Agent for on-premise AD and the native Entra connection for the cloud. See the Nmbrs to Entra ID guide.

Can I run more than one agent for high availability?
Yes. You can install the agent on multiple domain-joined servers so provisioning continues if one server is unavailable.
